TBS1072B-EDU -

Oscilloscope, 2-Channel, 70 MHz, Education Model

Tektronix TBS1072B-EDU
聲明：圖片僅供參考，請以實物為準！
制造商產品編號：
TBS1072B-EDU
倉庫庫存編號：
70336216
技術數據表：
View TBS1072B-EDU Datasheet Datasheet
訂購熱線： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于產品數據庫龐大，部分產品信息可能未能及時更新，下單前請與銷售人員確認好實時在庫數量，謝謝合作！

TBS1072B-EDU產品概述

The TBS1000B-EDU Digital Storage Oscilloscope Series is designed specifically to meet the needs of today's schools and universities. It's the first oscilloscope to use an innovative new Courseware system that enables educators to seamlessly integrate teaching materials onto TBS1000-EDU oscilloscopes. The Courseware information is presented directly on the oscilloscope display and can be used to provide; step by step instructions, background theory, hints and tips or an efficient way for students to document their lab work. The instrument includes a 7-inch WVGA TFT color display, up to 2 GS/s sampling rate, bandwidths from 50 MHz to 200 MHz, dual channel frequency counters and a 5 year standard warranty, just a few of the features that make the TBS1000B-EDU the industry's best value entry level oscilloscope for educational activities.

Key performance specifications
  • 200MHz, 150 MHz, 100 MHz, 70 MHz and 50 MHz bandwidth models
  • 2-channel models
  • Up to 2 GS/s sample rate on all channels
  • 2.5k point record length on all channels
  • Advanced triggers including pulse and line-selectable video triggers

    Key features
  • 7 inch WVGA (800×480) Active TFT Color Display
  • 34 automated measurements
  • Dual window FFT, simultaneously monitors both the time and frequency domains
  • Integrated Courseware feature
  • Dual channel frequency counter
  • Zoom Function
  • Autoset and signal auto-ranging
  • New affordable 50 MHz TPP0051 passive probes
  • Multiple-language user interface
  • Small footprint and lightweight - Only 4.9 in. (124 mm) deep and 4.4 lb. (2 kg)

    Connectivity
  • USB 2.0 host port on the front panel for quick and easy data storage
  • USB 2.0 device port on rear panel for easy connection to a PC

    • TBS1072B-EDU產品信息

      Bandwidth  70 MHz
      Brand/Series  TBS1000 Series
      Configuration  Bench
      Memory  2.5 Kpts
      Number of Channels  2
      Sample Rate  1 GS/s
      Type  Digital
    關鍵詞

    TBS1072B-EDU關聯產品

    • 參考圖片
    • 制造商 / 說明 / 型號 / 倉庫庫存編號
    • PDF
    • 操作
    参考价格及参考库存
      美国2号仓库    仓库直销，订单金额100元起订，满300元含运，满500元含税运，有单就有优惠，量大更优惠，支持原厂订货
    型号 制造商 描述 操作
    TBS1072B-EDU
    [更多]    		 Tektronix Inc

    Benchtop Oscilloscopes 70MHz, 2CH, 1GS/s with Courseware

    RoHS: Compliant

    		搜索
      新加坡2号仓库    仓库直销，订单金额100元起订，满300元含运，满500元含税运，有单就有优惠，量大更优惠，支持原厂订货
    型号 制造商 描述 操作
    TBS1072B-EDU
    [更多]    		 Tektronix Inc

    OSCILLOSCOPE, 2CH, 70MHZ, EDUCATION

    		搜索
      英国2号仓库    仓库直销，订单金额100元起订，满300元含运，满500元含税运，有单就有优惠，量大更优惠，支持原厂订货
    型号 制造商 描述 操作
    TBS1072B-EDU
    [更多]    		 Tektronix Inc

    "Oscilloscope, 2-Channel, 70 MHz, Education Model"

    RoHS: Not Compliant

    		搜索
    查看资料
      日本5号仓库    仓库直销，订单金额100元起订，满300元含运，满500元含税运，有单就有优惠，量大更优惠，支持原厂订货
    型号 制造商 描述 操作
    TBS1072B-EDU
    [更多]    		 Tektronix Inc

    Oscilloscope Dimensions L x W x H: 125 x 327 x 158 mm Time basis: 2.5 ns/div...50 s/div Vertical sensitivity/div: 2 mV...5 V/div Weight: 2 kg Delivery with: 1 Probes / Channel / Documentation CD / Power Cable / Software / Calibration Certificate Display: 7" TFT-LCD Electrical supply: 100...240 V @ 50...60 Hz Input coupling: AC / DC / GND Input impedance Ohm: 1 MOhm Instrument functions: Frequency Counter Interfaces: USB Mathematical functions: Add / FFT / Subtract / Multiply Measuring function: Data logger / Duty cycle / Mask testing / Min./max. value Safety standard EN 61010: CAT II 300 V Series: TBS1000B-EDU Trigger: Auto / Edge / Pulse width / Video / Single / Stop

    		搜索
    查看资料
    TBS1072B-EDU +CAL
    [更多]    		 Tektronix Inc

    Oscilloscope Dimensions L x W x H: 125 x 327 x 158 mm Time basis: 2.5 ns/div...50 s/div Vertical sensitivity/div: 2 mV...5 V/div Weight: 2 kg Calibration: Calibration Delivery with: 1 Probes / Channel / Documentation CD / Power Cable / Software / Calibration Certificate Display: 7" TFT-LCD Electrical supply: 100...240 V @ 50...60 Hz Input coupling: AC / DC / GND Input impedance Ohm: 1 MOhm Instrument functions: Frequency Counter Interfaces: USB Mathematical functions: Add / FFT / Subtract / Multiply Measuring function: Data logger / Duty cycle / Mask testing / Min./max. value Safety standard EN 61010: CAT II 300 V Series: TBS1000B-EDU Trigger: Auto / Edge / Pulse width / Video / Single / Stop(ISO CALIBRATED)

    		搜索
    查看资料
      英国10仓库    查看更多相关产品
    产品描述 / 参考图片 制造商零件编号 / 制造商 / 库存编号 操作

    Tektronix - TBS1072B-EDU - Tektronix TBS1000 系列 2通道 70MHz 数字示波器 TBS1072B-EDU, TFT LCD显示
    		制造商零件编号：
    TBS1072B-EDU
    品牌：
    Tektronix
    库存编号：
    800-2990
    		搜索
      新加坡2号仓库    查看更多相关产品
    制造商产品编号 仓库库存编号 制造商 / 说明 / 规格书 操作
    TBS1072B-EDU
    TEKTRONIX TBS1072B-EDU    		2383222

    TEKTRONIX

    2 Channel 70MHz Digital Storage Oscilloscope for Educational Activity with 7inch WVGA TFT Display

     (EN)    		搜索
      英国2号仓库    查看更多相关产品
    参考图片 制造商 / 说明 / 型号 / 仓库库存编号 PDF 操作

    Tektronix - TBS1072B-EDU - Education Model 70 MHz 2-Channel Oscilloscope|70336216 | ChuangWei Electronics    		Tektronix
    Oscilloscope, 2-Channel, 70 MHz, Education Model

    型号：TBS1072B-EDU
    仓库库存编号：70336216

    		搜索
      www.szcwdz.com    查看更多相关产品
    参考图片 型号/品牌 描述 / 技术参考 操作
    无图TBS1072B-EDU
    Tektronix    		Benchtop Oscilloscopes 70MHz, 2CH, 1GS/s with Courseware
    暂无PDF     		查价格库存
    查看详细
    无图TBS1072B-EDU +CAL
    Tektronix    		Oscilloscope 2x70 MHz 1 GS/s
    暂无PDF     		查价格库存
    查看详细
      日本5号仓库    查看更多相关产品
    参考图片 制造商 / 说明 / 型号 / 仓库库存编号 PDF 操作

    Tektronix - TBS1072B-EDU - Oscilloscope 2x70 MHz 1 GS/s, TBS1072B-EDU, Tektronix    		Tektronix
    Oscilloscope 2x70 MHz 1 GS/s, TBS1072B-EDU, Tektronix

    型号：TBS1072B-EDU
    仓库库存编号：110-75-381

    		搜索

    Tektronix - TBS1072B-EDU +CAL - Oscilloscope 2x70 MHz 1 GS/s, TBS1072B-EDU +CAL, Tektronix    		Tektronix
    Oscilloscope 2x70 MHz 1 GS/s, TBS1072B-EDU +CAL, Tektronix

    型号：TBS1072B-EDU +CAL
    仓库库存编号：300-35-839

    		搜索
