P5100A產(chǎn)品概述
Performance you need at a price you can afford.
With up to 200 MHz bandwidth and 2 GS/s sample rate, the TDS2000C Oscilloscope Series provides you with affordable performance in a compact design. Packed with standard features – including USB connectivity, 16 automatic measurements, context-sensitive help, probe check wizard — the TDS2000C Series Oscilloscopes help you get more done, in less time.
Enhanced Features include:
New brighter display with wide angle viewing
Enhanced banner specification on most popular models over 10x sampling
New waveform pass/fail and data logging features
5 additional automated measurements
New TTP series probe with improved probe loading
Limited Lifetime Warranty
Features & Benefits
Key Performance Specifications
200 MHz, 100 MHz, 70 MHz, 50 MHz Bandwidth Models
2- and 4-channel Models
Up to 2 GS/s Sample Rate on All Channels
2.5k point Record Length on All Channels
Advanced Triggers including Pulse Width Trigger and Line-selectable
Video Trigger
Ease-of-Use Features
16 Automated Measurements, and FFT Analysis for Simplified
Waveform Analysis
Built-in Waveform Limit Testing
Automated, Extended Data Logging Feature
Autoset and Signal Auto-ranging
Built-in Context-sensitive Help
Probe Check Wizard
Multiple-language User Interface
5.7 in. (144 mm) Active TFT Color Display
Small Footprint and Lightweight — Only 4.9 in. (124 mm) Deep and 4.4 lb. (2 kg)
Connectivity
USB 2.0 Host Port on the Front Panel for Quick and Easy Data Storage,
Printing, and Connecting a USB Keyboard
USB 2.0 Device Port on Rear Panel for Easy Connection to a PC or
Direct Printing to a PictBridge® — compatible Printer
Includes National Instrument's LabVIEW SignalExpress™ TE Limited
Edition and Tektronix OpenChoice® Software for Connecting Your Bench
Datasheet
