Body Style | Rectangular | |
Brand/Series | E3Z Series | |
Current, Switching | 100 mA | |
Dimensions | 20 x 10.8 x 31 mm | |
Function | Proximity | |
Indicator | LED | |
IP Rating | IP67 | |
Light Source | Red (680nm) | |
Material, Body | PBT | |
Material, Lens | Denaturated Polyallylate | |
Mounting Type | Bracket | |
Output | NPN - Dark-ON/Light-ON - Selectable | |
Range, Measurement | 20 to 200 mm | |
Response Time | 1 ms | |
Sensing Mode | Reflective, Diffuse | |
Set Point | Five-Turn Endless Adjuster | |
Standards | CE Marked | |
Supply Voltage | 12 to 24 VDC | |
Technology | Photoelectric | |
Temperature Range | -25 to 55 degC | |
Temperature, Operating | -25 to +55 °C | |
Termination | Cable | |
Type | Diffuse | |
Voltage, Switching | 26.4 VDC | |
Weight | 65 g | |
