CP1LM40DRD -

CONTROL LOGIC 24 IN 16 OUT 24V

RoHS: Compliant | pbFree: Yes

CONTROL LOGIC 24 IN 16 OUT 24V

RoHS: Compliant | pbFree: Yes

Controllers CPU 24In 16 OutDC PS

RoHS: Compliant

High Performing Programmable Controller With Embedded Ethernet

RoHS: Compliant

CPU 24 IN, 16 OUT DC PS - Bulk (Alt: CP1L-M40DR-D)

CP1L CPU 24VDC 24x24VDC i/p 16xRelay

RoHS: Compliant

CPU 24 IN, 16 OUT DC PS CP1LM40DRD

Programmable logic controller Dimensions W x H x D: 150 x 110 x 85 mm Inputs: 24 digital, 1 analogue (Potentiometer 8 Bit), 2 high speed counter Inputs, abbreviated: 24 DI, 1 AI (Potentiometer 8 Bit), 2 HS Operating temperature: 0...+55 °C Outputs: 16 relay Outputs, abbreviated: 16 RO Analogue inputs: Potentiometer 8 Bit Certification: CE, UL, Lloyds Communications interface: 1 x USB Data buffer: Battery, for maxum 5 years Data memory: 32 kWords Expandability: 3 modules Inputs/outputs, max.: 160 Internal program memory: 10 kSteps Operating voltage: 24 VDC Processing time per binary statement: 0.55 μs Real-time clock: yes Series: CP1 Switching capacity: 2 A @ 24 VDC / 250 VAC Protection rating: IP 20 Termination type: Screw Terminal, Removable No. of analogue inputs: 1 No. of digital inputs: 24 No. of high speed counter: 2 No. of relay outputs: 16

CPU 24 IN, 16 OUT DC PS
